CS55 Racing Kart - ROOKIE EVM - 950mm
OPTIMIZED DRIVING POSITION
New pedals
Among the most significant innovations introduced with the 2025 edition of the EVM is the innovative forged aluminium pedals - inspired by the solutions already adopted for the Senior models. The drivers comfort is also improved with the introduction of a new fuel tank with an optimized shape to make driving more comfortable.
TOP COMPONENTS
Magnesium hubs and BMT4 spindles
In categories such as Cadet9 and Cadet12 , victory is often a matter of thousandths of a second, therefore, a continuous refinement of every single component of the kart is absolutely necessary. The work of the OTK Kart Group R&D department has led to the development of the new BMT4 spindles, combined with 235 mm tie rods. New magnesium hubs now come standard on both front and rear axles along with a new chain tensioner fixed to the bearing bracket.
MAXIMUM AERODYNAMIC EFFICIENCY
M9 Bodywork Kit
The EVM chassis is equipped with the innovative M9 Nassa Panel and Nose Cone kit, strongly inspired by the M11 model on the Senior kart. The side pods and rear bumper remain unchanged. Attention to detail at the aerodynamic level is evidenced by the introduction of a new integral floor tray, able to reducing vortex and turbulence ultimately leading to better laptimes
OPTIMIZED BRAKING
BSM5 Brake System
To meet the specific needs of the Cadet categories, OTK have implemented innovative solutions to improve the braking on the EVM model by updating the already well-known BSM5 brake system with new brake pads named 4A and a 149 mm floating rear disc
FEATURES
| > Frame Material: | >> Chrome Moly |
| > Tubes Diameter: | >> 28 mm |
| > Wheelbase: | >> 950 mm |
| > Rear Axle: | >> 30 mm |
| > Brake System: | >> BSM5 / CIK-FIA homologated |
| > Bodyworks: |
>> M9 Nassa Panel >> M9 Nose Cone >> M8 side pods >> Sticker Kit with new 2025 graphics |
| > Supplied Accessories: |
>> Aluminium machined components |
________________________________________________________________
Please note:
Chassis DOES NOT include an engine kit or tyres!
